TM8100/TM8200 Service Manual Spare Parts 443
© Tait Electronics Limited June 2006
Table 16.3 Spare parts of the control heads with 1- or 2-digit display
Pos. Description Qty. IPN Spares Kit
a
B
Control-head loom (with female/female adaptor)
– female-female adaptor
1 219-02882-xx
210-00021-41
TMAA22-01 and 90
C
Control-head options board (optional)
– dynamic microphone board 1 – TMAA02-06
D
3 x 8 PT screw 3 346-10030-08 TMAA22-01 and 90
E
Control-head board (2-digit display)
Control-head board (1-digit display)
1
1
–
–
TMAA22-03 (x6)
TMAA22-91 (x6)
F
Elastomeric strip 2 209-00011-xx TMAA22-01 and 90
G
Space-frame 1 319-30073-xx TMAA22-01 and 90
H
Front-panel assembly 1 – TMAA22-01 and 90
I
Knob for volume-control potentiometer 1 311-01054-xx TMAA22-01 and 90
J
Speaker 1 252-00011-xx TMAA22-01 and 90
1)
Concealed microphone (optional) 1 – TMAA02-06
1!
LCD 1 008-00031-xx TMAA22-01 and 90
1@
Keypad 1 311-03114-xx TMAA02-01 and 90
1#
Short light pipe 1 262-00003-xx TMAA22-01 and 90
1$
Long light pipe 1 262-00004-xx TMAA22-01 and 90
The characters xx in an IPN stand for the issue number. Items will always be the latest issue at the time the
radio is manufactured.
a. Spares kit TMAA22-01 contains an assembled 2-digit-display control head without the control-head board.
Spares kit TMAA22-90 contains an assembled 1-digit-display control head without the control-head board.
Neither spares kit includes the optional parts of the concealed microphone.
