Tait TM8110 Service Manual

Ref. IPN Description Ref. IPN Description
Ref. PCB Circuit Ref. PCB Circuit
Ref. PCB Circuit
TM8100/TM8200 Service Manual Installing an Enhanced Remote Kit 537
© Tait Electronics Limited June 2006
R701 038-16120-10 RES 0603 120k 1% 1/10W
R710 036-13100-10 RES 0805 100R 1% 1/8W
R720 038-15100-10 RES 0603 10k 1% 1/10W
R721 038-14220-00 RES 0603 2k2 5% 1/10W
R722 038-14470-10 Res 0603 4k7 1% 100ppm
R730 038-12470-00 RES 0603 47R 5% 1/10W
R731 038-12470-00 RES 0603 47R 5% 1/10W
U300 002-10800-00 IC LDO REG LF80C 8V@1A PPAKT/R
U310 002-14931-00 IC L4931CD33 3.3v 250Ma Regso8
U400 002-19120-00 IC TS912ID Cmos R2R Opamp
U500 002-13483-00 IC XCVR RS485 LTD SLEW RATE 3V
U600 002-15595-00 IC 74AHC595 8bit Shiftreg Tsop
U610 002-10126-71 IC SMD DS1868 Dgtl Pot Tsop20
U700 002-13001-00 IC TPA3001 20W Mono PA TSSOP24
220-01721-04 PCB MFX Head Remote
219-02914-00 LOOM MFX Remote Head
302-05263-00 Brkt U Thumb Scrw TMA
302-10062-00 Brkt Remote Head TM8200
316-06842-00 Pnl Rear TM8200 MF2
346-10030-08 Scrw P/T Wn1412 Kc30x08 Zbc
349-00060-00 Scrw 10G*20 SLFDRL Hex/Poz TMA
353-05007-00 Wshr Rubber M4*19*1.0 S/A
354-01052-00 Fsnr Bush PSM SHK-B-M4 Ins
402-00015-00 MANL f/instr TMAA03-05
410-01183-02 Pkg Box 220x82x65 TMA
410-01197-01 Pkg Ins Lg Ctrl Hd TMA
TMAA04-01 Remote Cable Parts
219-02918-00 Cbl Rmt Ctrl Hd Kit, comprising:
219-00025-00 loom 6m shld Bonded+Drain
240-02158-00 Conn Shld RJ45 Shortbody Plg
360-02022-00 Grommet Mic TMA
Grid Reference List
C1 D1 D7
C100 J3 E3
C101 L4 E3
C102 J4 E3
C103 J4 E3
C110 L4 F4
C300 M5 G2
C301 N5 G3
C310 M2 G4
C311 N2 G4
C312 M2 G5
C320 P4 D8
C400 L3 G10
C401 L3 G10
C410 M3 G8
C411 M3 G8
C420 L3 G5
C421 L3 G6
C422 K3 F7
C423 K3 F7
C430 M2 G9
C500 L4 F6
C600 L2 C3
C601 L2 B2
C610 K1 C5
C611 K1 C4
C612 J2 C5
C700 F2 C6
C701 G3 C7
C702 E3 C7
C703 E2 C6
C704 G2 C6
C705 F2 B6
C706 E3 B6
C707 E2 B6
C708 G2 A6
C710 E2 D6
C711 F2 D7
C712 E2 D7
C720 F1 D2
C721 G1 D2
C730 E3 B8
C731 G3 A8
C732 F4 B9
C733 G4 B9
C734 F4 B10
C735 F4 B9
D100 K3 F4
E4
D101 K4 E4
F4
D102 K4 F4
E4
D103 K4 E5
F5
D104 K5 E5
D110 L5 F3
D201 K5 E8
D211 K5 C9
D300 N5 G3
D301 M5 G2
D720 G1 D2
D730 F3 B7
D731 G3 B7
E100 J5 E2
E101 H5 E2
E102 K4 F3
E103 K4 E4
E105 H5 F2
E710 F2 D7
E711 E2 D7
E730 E4 B8
E731 G4 B8
J100 H4 E1
J200 P3 E10
J201 B4 C10
L712 D2 D8
L730 E4 B9
L731 G4 B9
MT800 D3 B5
MT801 M3 B5
Q610 K1 D4
Q720 F1 D2
Q721 G2 D3
R100 J3 F2
R110 L4 F3
R200 N4 F8
R201 R3 E8
R202 R2 E8
R203 J5 E1
R210 C3 D9
R211 B3 C9
R212 B4 C9
R213 J5 D1
R320 N4 E8
R321 M4 E8
R401 L3 G10
R402 L3 G10
R410 M3 G8
R411 M3 G7
R412 L4 G7
R420 L3 G6
R421 L3 G6
R422 K3 F7
R430 M2 G9
R431 M2 G9
R440 K3 E5
R441 K3 D5
R442 J3 D5
R501 M4 E7
R510 K4 F6
R511 K4 F6
R600 L2 B1
R601 L2 B2
R602 L1 C1
R603 L2 C1
R604 L2 B1
R605 L2 B3
R606 M2 B3
R607 M2 B3
R608 M2 B3
R609 M2 B4
R610 J2 B5
R611 K1 C4
R612 K1 D4
R701 E3 B6
R710 F2 D6
R720 F1 D1
R721 F1 D2
R722 G1 D2
R730 E3 B7
R731 G3 A7
U300 P5 G3
U310 N2 G4
U400 L3 F6
G7
1G9
U500 L4 F7
U600 L2 B2
U610 K2 B4
U700 F3 B7
