Tait TM9300 User Manual

108 Operating in trunked mode
Sending a preset text message
1 Press Menu and select Send > Text message >
Preset message.
In the Preset message menu, a short label
representing each message is displayed.
2 Scroll through the list of preset message labels
until the one you want appears.
3 Press Select, and the text message you have
chosen is now displayed.
4 Press Send to send the message, or Edit to
change the message.
Pressing will place the cursor at the start of the
message. Pressing will place the cursor at the
end of the message. When the message is
complete, press Options and select Send.
Creating a new text message
1 Press Menu and select Send > Text message >
New message.
2 Use the alphanumeric keys to add characters and
the Clear key to delete them. Use the scroll keys to
move through the characters.
SelectBack
Text message
Preset message
Edit message
SelectBack
Preset message
Contact
Site
Send
Contact base now
Back Edit
Options
On site|
Clear
abc
7/100

Tait TM9300 Specifications

General

Modulation	FM, 4FSK (DMR)
IP Rating	IP54
GPS	Optional
Bluetooth	Optional
Frequency Range	450-520 MHz
Channel Spacing	12.5 / 25 kHz
Operating Modes	Analog FM
Dimensions	160 x 60 x 40 mm (without antenna)
Weight	1.6 kg (3.53 lbs)
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Power Output	5 W, 25 W, 50 W
RF Output Power	5 W, 25 W, 50 W
