Before using your radio 33
6 Rotate the lever counterclockwise until you hear
it click.
7 Check that the accessory connector is firmly
locked into place.
Installing an RF speaker
microphone
Once you have attached the accessory connector to
the radio, you can attach the coax cable of the RF
speaker microphone to the radio’s antenna connector
and then screw the radio’s antenna onto the speaker
microphone.
1 Remove the antenna from the radio.
2 Place the brass RF coaxial connector onto the
radio’s antenna connector.
3 Tighten the connector with the 5/16 inch spanner,
until it sits deep in the radio housing.
coaxial connector
