141
MAINTENANCE
Replacing the Hub Gear Oil
WARNING
� Stop the engine and allow the machine
to cool down before performing
maintenance.
• The hubs are hot directly after the
engine is stopped. Touching them will
cause burns.
• The gear oil is also hot and under high
pressure.
Be careful when loosening plugs.
Working on the machine under these
conditions could result in burns or
injuries.
�
The pressure in the hubs reduction
gears case may cause oil or the plug
to fly out. Loosen the plug slowly to
release the pressure.
1. Set the hub so that the plug (1) is at the
very bottom.
2. Park the machine on a level surface. Stop
the engine.
3. Place a pan for catching the spent oil under
plug (1).
4. Remove plug (1) and drain the oil.
5. Set the hub so that plug (1) is at the level.
Every 1500 Hours
6. Supply oil through the hole for plug (1) until
oil flows out of the hole of plug (1).
7. Tighten plug (1).
Inspecting and Cleaning the
Engine Fuel Injectors
This operation requires experience. Have
it performed by a Takeuchi sales or service
outlet.
Inspecting the Turbocharger
(Blower wash as necessary)
This operation requires experience. Have
it performed by a Takeuchi sales or service
outlet.
Inspecting and Cleaning the EGR
Valve, Lead Valve and Cooler
This operation requires experience. Have
it performed by a Takeuchi sales or service
outlet.
Inspecting the Crankcase
Breather System
This operation requires experience. Have
it performed by a Takeuchi sales or service
outlet.
To Next Page
