Takeuchi TB175W User Manual

51
CONTROLS
............ The suspension is automatically
locked if the brake is pressed
when traveling at low speed (1st
speed:
), and it is unlocked
when the brake is released.
When traveling at high speed (2nd
speed: site travel switch is off), the
suspension is not locked even if
the brake is pressed.
4. Creeping Travel Switch
Depress the “creeping gear” symbol on
this switch to change the travel speed from
site travel to creeping travel gear.
This switch only functions when the site travel
switch is on.
Slow down sufficiently when switching the
travel gear.
Depress the other side of the switch to
change into site travel gear.
5. Site Travel Switch
Depress the “slow” symbol on this switch
to change the travel speed from road travel
to site travel gear.
Stop the machine and engage the brake
pedal lock and then shift the travel gear.
Depress the other side of the switch to
change into road travel gear.
6. Parking Brake Switch
Depress the parking brake symbol on
this switch to engage the parking brake.
Depress the other side of the switch to
disengage the parking brake, when the safety
lock lever is fully lowered to the unlocked
position while the engine is running.
Control Console
Indicators
7. Working Light Indicator Lamp
This lamp illuminates when the work lights
are turned on.
8. Brake Oil Pressure Warning Lamp
CAUTION
Wait 5 seconds after this lamp has gone
out before operating the machine.
If this lamp is illuminated while traveling on
a road, pull over as soon as possible.
This lamp illuminates when the brake oil
pressure drops abnormally while the engine
is running.
9. Turn Signal Indicator Lamp
This lamp blinks when the turn signal
switch or hazard switch is operated.
10. Safety Lock Button
CAUTION
Before traveling on a road, use this button
to lock the right and left operating levers.
The button operates when the lock lever
is in the free position.
If the button is pressed, the hoe attachment
cannot move, even if the operating levers are
accidently engaged. In this configuration, the
light comes on in the switch.
The operating levers are re-activated by
pressing the switch again.
AUTO
