63
CONTROLS
Accessories
Selector valve
Open ..............When using a hydraulic
breaker (One-way flow)
Closed ............When using a reversible
attachment (Two-way flow)
Change the direction of the hydraulic oil flow
by opening or closing the selector valve on
the machine body.
External Power Sockets (for EU)
WARNING
Only use applicable electric products with
those sockets.
for Beacon
Use those sockets as an external power
supply. When using this socket, be careful
not to exceed 12V/5A.
To use, raise the cap (1).
Interior Light
IMPORTANT: The battery capacity will
decrease if the interior light is left on for
long periods of time the engine stopped.
Turn the lamp off when leaving the
machine.
OFF .......... Lamp is turned off all the time.
ON ............ Lamp is turned on all the time,
with no regard for the door being
opened or closed.
Closed
Open
1
/ 1-way
/ 2-way
W2C002E
To Next Page
