2-45
CONTROLS
LIFT OVERLOAD WARNING SWITCH
(IF EQUIPPED)
If the overload is not removed after the
overload warning horn is sounded, the
machine may tip over. If the horn starts
sounding, stop operating the machine
and lighten the load.
If a weight greater than the lifting capacity is
applied or lifted, the overload warning device
is activated and the horn sounds. (When the
lift overload warning switch is turned on.)
OFF ....Off
ON .....On
SWITCHES
BEACON LAMP SWITCH
When this switch is turned on while the
starter switch is at ON, the lamp turns on as
follows:
OFF ....Off
ON .....Beacon lamp is lit
