Takeuchi TB225 User Manual

2-9
CONTROLS
CAB
CAB
CAB DOOR
When getting on or off the cab, first open
the door all the way until it is secured in
the catch and check that it does not
move.
Open the door fully and press it against the
catch at the back of the door to secure it in
place.
The door must be locked when getting on or
off the machine and while in operation.
Locking and unlocking
Insert the starter key and turn it.
Opening
1. Pull the knob (1) towards you and open
the door.
To open the door from inside the cab, hold
the door opener (2).
2. Open the door fully and press it against
the cab to secure it in place.
Closing
1. Push the release lever (3) to the lower.
2. Close the released door.
EMERGENCY EXIT
Front window (excluding machines with a
front guard)
If you should become trapped inside the
cab, open the front window to get out.

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
