Takeuchi TB225 User Manual

8-4
OPTIONS
ATTACHMENT COMBINATION TABLE
The table below shows which bucket should be installed when the machine is using a long
arm. Select a proper bucket by following the table.
• Consult with Takeuchi before installing an optional attachment.
• Do not use any attachments not approved by Takeuchi. Doing so may cause safety
problems. Or, it may adversely affect the machine’s operation or service life.
• We will not be held responsible for any injuries, accidents or damage to its products
caused by the use by a non-approved attachment.
• The swing stopper must be mounted when a bucket wider than a 500W bucket is
mounted. Failure to mount the swing stopper may result in the bucket hitting the
machine body.
√ :Can be used.
∆ :Can be used only for light operations (digging and loading of dry and loose soil or mud)
— :Cannot be used.
Total bucket mass = Bucket mass + Heaped bucket load (specific gravity: 1.8)
ATTACHMENT COMBINATION TABLE
Bucket
Rated capacity
m
3
(cu. yd.)
Bucket cutting
width
mm (inch)
Standard arm
1120 mm
(44.1 in.)
Long arm
1245 mm
(45 in.)
500W 0.064 (2.26) 500 (19.7) √ √
Total bucket mass
= Within 167 kg (368 lb.)
Within 500 (19.7) √ √

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
