Takeuchi TB225 User Manual

3-13
OPERATION
When the dozer blade is in front of the
operator’s seat:
To move forward:
Tilt the levers forward.
To move backward:
Tilt the levers backward.
OPERATING THE MACHINE
When the dozer blade is behind the
operator’s seat:
To move forward:
Tilt the levers backward.
To move backward:
Tilt the levers forward.
Traveling in 2nd (High) speed
When a load greater than a set value is
applied during traveling in 2nd (high)
speed, the speed will automatically slow
down to 1st (low) speed. When the load
becomes lighter, the speed will increase
and return to 2nd (high) speed. It should
be noted that the travel speed changes
depending on the load condition (for
machines with the automatic travel shift-
down system).
Press the travel speed switch on the right
travel lever to switch to 2nd (high) speed,
and press it again to return to 1st (low)
speed.

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
