Takeuchi TB225 User Manual

3-23
OPERATION
Braking when descending slopes
When descending slopes, the brakes are
applied automatically once the travel levers
are returned to the neutral position.
If the crawler slips
If the crawler slips while climbing a slope and
impossible to travel, use the pulling force of
the arm to climb the slope.
OPERATING PROCEDURES
If the engine stops when descending a
slope, set the travel levers to the neutral
position, stop the machine, then start the
engine.
Do not open the door while traveling on
slopes
If the engine stops
Opening the door while traveling on slopes is
dangerous, as the force required to open
and close the door changes abruptly. Always
keep the door closed when traveling on
slopes.

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
