Takeuchi TB225 User Manual

6-11
TROUBLESHOOTING
Warning lamp Lamp name Causes and remedies
Coolant
temperature
warning lamp
The coolant temperature is too high and the engine is
overheating.
Refer to “If the engine overheats” on page 6-3.
Air cleaner
warning lamp
The air cleaner is clogged. Clean it.
Refer to “Cleaning the air cleaner” on page 5-38.
Fuel level
warning lamp
The fuel level is too low. Add fuel.
Refer to “Inspecting the fuel level” on page 5-20.
Third auxiliary
hydraulic
warning lamp
Pressure in the third auxiliary hydraulic line is too low
Consult your sales or service dealer for help.
Lift overload
warning
indicator lamp
This lamp starts flashing if the overload warning device is
activated. If it occurs, reduce the load to be lifted.
Refer to “Lift overload warning switch (If equipped)” on
page 2-45.
IF A WARNING LAMP FLASHES

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
