Takeuchi TB225 User Manual

6-13
TROUBLESHOOTING
Error code Error details
6519 AUX1 (L) switch error
6529 AUX1 (R) switch error
6603 AUX2 slide switch voltage value error (too high)
6604 AUX2 slide switch voltage value error (too low)
6609 AUX2 slide switch neutral error
6709 AUX3 button error (Foot)
6719 AUX3 switch error (Grip)
8015 AUX1 (L) PWM output voltage error (too low)
8016 AUX1 (L) PWM output voltage error (too high)
8025 AUX1 (R) PWM output voltage error (too low)
8026 AUX1 (R) PWM output voltage error (too high)
8035 AUX2 (L) PWM output voltage error (too low)
8036 AUX2 (L) PWM output voltage error (too high)
8045 AUX2 (R) PWM output voltage error (too low)
8046 AUX2 (R) PWM output voltage error (too high)
8054 Throttle motor A (too low)
8064 Throttle motor B (too low)
VEHICLE ERROR CODE LIST
PWM = Pulse width modulation
