Takeuchi TB225 User Manual

7-7
SPECIFICATIONS
MACHINE DIMENSIONS
Canopy
Unit: mm (inch)
Item
Long arm Standard arm
Rubber crawlers
A Overall length 4180 (164.6) 4165 (164)
B Upperstructure overall width 1100 (43.3)
C Overall height 2355 (92.7)
D Slew radius 1240 (48.8)
E Clearance height under upperstructure 505 (19.9)
F Crawler base 1415 (55.7)
G Crawler overall length 1790 (70.5)
H Crawler overall width (narrow) 1100 (43.3)
H
2
Crawler overall width (wide) 1500 (59.1)
J Crawler shoe width 250 (9.8)
K Ground clearance of undercarriage 190 (7.5)
L Minimum radius of equipment and attachment 1830 (72) 1810 (71.3)
M
Minimum radius of equipment at maximum front
offset
1485 (58.5) 1465 (57.7)
P Offset distance of bucket (right swing) 450 (17.7)
Q Offset distance of bucket (left swing) 575 (22.6)
R Dozer blade width (narrow) 1100 (43.3)
R
2
Dozer blade width (wide) 1500 (59.1)
S Dozer blade height 300 (11.8)
T Front distance to axis of rotation 2940 (115.7) 2925 (115.2)
U Dozer blade distance to axis of rotation 1400 (55.1)
V Boom swing angle (Left) 75°
W Boom swing angle (Right) 55°
X Overall length (dozer blade at rear) 4375 (172.2) 4360 (171.7)

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
