Takeuchi TB225 User Manual

7-9
SPECIFICATIONS
Standard arm
OPERATING RANGES
Unit: mm (inch)
Item Rubber crawlers
A Maximum reach 4255 (167.5)
B Maximum reach at ground reference plane 4130 (162.6)
C Maximum digging depth 2455 (96.7)
D Maximum vertical digging depth 1980 (78)
E Reach at maximum vertical digging depth 2720 (107.1)
F Maximum height of cutting edge 3985 (156.9)
G Maximum dumping height 2800 (110.2)
H Minimum dumping height 1035 (40.7)
J Dozer blade maximum lifting 335 (13.2)
K Dozer blade maximum lowering 330 (13)
Long arm
Unit: mm (inch)
Item Rubber crawlers
A Maximum reach 4375 (172.2)
B Maximum reach at ground reference plane 4250 (167.3)
C Maximum digging depth 2580 (101.6)
D Maximum vertical digging depth 2100 (82.7)
E Reach at maximum vertical digging depth 2750 (108.3)
F Maximum height of cutting edge 4060 (159.8)
G Maximum dumping height 2875 (113.2)
H Minimum dumping height 910 (35.8)
J Dozer blade maximum lifting 335 (13.2)
K Dozer blade maximum lowering 330 (13)

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
