Takeuchi TB225 User Manual

2-17
CONTROLS
INSTRUMENT CLUSTER
1. Vehicle and engine emergency lamp
This lamp flashes and an alarm sounds if
there is a problem with the machine. Go to
the “Failure record (FAILURE RECORD)”
from the side menu screen, get the vehicle
error code number, and then consult your
sales or service dealer referring to the
“Vehicle error code list” in this manual.
Refer to “Side menu screen” on page
2-28.
Refer to “Failure Record (FAILURE
RECORD)” on page 2-35.
Refer to “Vehicle error code list” on pages
6-12 and 6-13.
2. Engine oil pressure warning lamp
This lamp flashes and an alarm is sounded
if the lubricant oil pressure abnormally low
while the engine is running.
3. Battery charge warning lamp
This lamp flashes and an alarm is sounded
if a problem rises in the charging system
while the engine is running.
4. Coolant temperature warning lamp
This lamp flashes and an alarm is sounded
if the engine coolant temperature
becomes abnormally high while the engine
is running.
5. Fuel level warning lamp
This lamp turns on if the fuel level
becomes low while the starter switch is in
the ON position.
6. Air cleaner warning lamp
This lamp flashes and an alarm is sounded
if the air cleaner filter is clogged while the
engine is running.
7. Safety start warning lamp
This lamp appears enlarged on the display
and the buzzer sounds if the engine is
started when the safety lock lever is in the
unlock position. The engine cannot be
started. First, set the safety lock lever to
the lock position, and then start the
engine.

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
