Takeuchi TB225 User Manual

2-23
CONTROLS
INSTRUMENT CLUSTER
FUNCTION OF EACH KEY
The functions are as below in the Home
screen. The different functions appear in the
other screens.
A. Stopping the alarm or switching the
display between Functions and
Warnings
· Pressing the (A) key while the alarm is
sounding stops the alarm.
· Pressing the (A) key to switch the
display; Functions (Page 1), Functions
(Page 2), and Warnings (Page 3).
B. Meter switching
Pressing and holding the (B) key for two
seconds or more each time the display
changes as follows:
1. Hour meter
3. Trip meter 2
4. Trip meter 3
5. Returns to the hour meter
· When the (B) key is pressed, the display
changes in the following order.
2. Trip meter 1

Takeuchi TB225 Specifications

General

Engine Make	Yanmar
Max Dig Depth	2, 580 mm
Bucket Capacity	0.03 - 0.11 m3
Max Reach	7, 010 mm
Max Digging Depth	3, 870 mm
