Takeuchi TB28FR User Manual

170
OPTIONS
3-Holes Bucket
The digging capacity increases when the
bucket’s link arm installation position is
switched from (A) to (B). However, this
shortens the bucket stroke.
• Struck capacity (SAE):
0.075 m
3
(0.098 cu. yd.)
• Rated capacity (SAE):
0.093 m
3
(0.121 cu. yd.)
Changing the Link Arm
Installation Position
Refer to page 131 “Replacing the Bucket” in
the manual.
OL1L170
A
B
OL1L180
