55
CONTROLS
Accessories
2. Stop the engine and open the selector
valve (1) on the machine body.
(The residual pressure is released from
the (D) port line.)
Selector valve
O: Open .......When using a hydraulic
breaker (1-way flow)
S: Closed..... When using a reversible
attachment (2-way flow)
Change the direction of the hydraulic oil flow
by opening or closing the selector valve on
the machine body.
External Power Socket (for EU)
¡Only use applicable electric products
with this socket.
¡Always replace the cap after using the
socket.
Use this socket as an external power
supply. When using this socket, be careful
not to exceed 12V/10A.
To use, remove the cap (1).
WARNING
1-way
2-way
1
S
O
F4B012
F4B013
1
To Next Page
