1.1.1 Key Features
Intel® Atom™ E3827 (1.75GHz) / E3845 (1.91GHz) / Celeron® J1900 (2.0GHz) Dual or Quad Core processor
1x DDR3L SO-DIMM max. up to 4GB
Dual Independent Display from 1x DVI-I and 1x DisplayPort
2x Intel® GbE port, support Wake-on-LAN and PXE
1x USB 3.0, 3x USB2.0
6x RS232/422/485 port
4x Isolated DI, 4x Isolated DO
1x 2.5” SATA SSD/HDD bay, 1x mSATA and 2x SIM card socket
9~48VDC wide range power input, support AT/ATX mode
2x Mini-PCIe slot for Wi-Fi, GSM, or I/O expansion
1x Remote power on/off switch
Universal I/O bracket for Mini-PCIe expansion
1.1 Overview
Based on Intel® Atom™ E3827 (1.75GHz) / E3845 (1.91GHz) or Celeron® J1900 (2.0GHz) Dual or Quad
Core processor, Rugged Mini E1 is a fanless embedded system. It offers modularize expansion I/O,
rich connectivity interfaces, wide range (9~48V) DC power input, and high reliability even operating in
temperature extremes (-25
°
C ~ +70
°
C).
Featuring with completely cable-less designed, high functional, one-piece housing design, and anti-
vibration, Rugged Mini E1 is a ruggedized system that can operate in harsh environments and is easy
to install and maintain. A build in over voltage protection (OVP), over current protection (OCP),
reserve voltage protection, and wide range DC power input makes Rugged Mini E1 a safety system for
all industrial applications.
Chapter 1: Product Introductions
Rugged Mini E1
