Tangent Rugged Mini E1 - Hardware Specification

Rugged Mini E1 | User’s Manual
Processor System
• Onboard
Intel® Atom™ E3827 / E3845 / J1900 Dual or
Quad Core Processor, 1.75GHz / 1.91 / 2.0 GHz with
AMI 64Mbit SPI BIOS.
Memory
• 1x 204-Pin DDR3L-1066/ 1333MHz SO-DIMM (un-
buffered and non-ECC), max. up to 4GB
Display
Dual Display
• 1x DVI-D and 1x VGA (w/ Optional Split Cable)
Expansion
• 2x Full-size Mini PCIe Socket for Wi-Fi / GSM / Expansion
Module
Ethernet
• 2 x Intel® I210-AT GbE LAN Port, Support Wake-on-LAN
and PXE
Audio
• Realtek ALC888S Audio Codec
• 1x Mic-in and 1x Line-out
Watchdog Timer
• Software Programmable Supports 1~255 sec. System
Reset
Storage
• 1x mSATA (share by 1x Mini-PCIe Socket)
• 2x External SIM Card Socket
I/O Ports
• 1x USB 3.0 Port
• 3x USB 2.0 Port
• 2 x DB9 for COM1~2, Support RS232/422/485 with Auto
Flow Control
• 4 x DB9 for COM1~4, Support RS232/422/485 with Auto
Flow Control
• 3x Antenna Hole
• 4x Antenna Hole
• 1x Power Switch
• 1x Remote Power Switch
• 1x Reset Hole
• 1x AT/ATX Switch
Digital Input & O
utput
• 4x Digital Input (Source Type)
- Input Voltage (Dry Contact):
Logic 0: Close to GND
Logic 1: Open
- Input Voltage:
Logic 0: 3V max.
Logic 1: 5V min. (DI to COM-)
• 4x Digital Output
- Supply Voltage: 5~30VDC
- Sink Current: 200 mA Max. Per Channel
Power
• Support AT, ATX Mode
• 1x 3-pin Terminal Block Connector with Power Input
9~48VDC
• 1x Optional AC/DC 12V/5A, 60W Power Adapter
Environment
• Operating Temperature: Ambient with Air Flow:
-25°C to 70°C (with Industrial Grade Peripherals)
• Storage Temperature: -30°C to 85°C
• Relative humidity: 10%~95% (non-condensing)
Physical
•
Dimension (WxDxH, mm):
150 x 105 x 37 mm
• Weight: 0.69 ~1.11 kg
• Construction: Extruded Aluminum with Heavy Duty
Metal
• Mounting: Wall, Optional VESA / Side / DIN-Rail
Mounting
Operating System
• Windows® 8
• Windows® 7
• Windows® Embedded Standard 7
Certifications
• CE
• FCC Class A
1.2 Hardwar
e Specification
Chapter 1: Product Introductions
9
