Rugged Mini E1 | User’s Manual
2.2 Connector / Switch Definition
List of Connector / Switch
Connector Location Definition
AT_ATX1 AT / ATX Power Mode Switch
CLR_CMOS1 Clear BIOS Switch
PWR_SW1 Power Switch
PWR_LED1 Power LED Status
HDD_LED1 HDD Access LED Status
WDT_LED1 Watchdog LED Status
USB2_1, USB2_2, USB2_3 USB 2.0 Port
USB3_1 USB 3.0 Port
LAN1, LAN2 LAN Port
SIM1, SIM2 SIM Card Socket
LINE_OUT1 Line-out Jack
MIC_IN1 Mic-in Jack
PWR_SW2 Remote Power Switch
RESET1 Reset Switch
DC_IN1 3-pin DC 9~48V Power Input Connector
DVI_I1 DVI-I Connector
COM1_1, COM2_1, CN1, CN2 RS232 / RS422 / RS485 Connector
DP1 DisplayPort Connector
DIO1 4DI / 4DO Connector
MINIPCIE1 Mini PCI-Express Socket
CN3 Mini PCI-Express / mSATA Socket
SATA1 SATA with Power Connector
