CUNNINGHAM
Most Tanzer22 mainsails are fitted with a cringle (86) in the luff a few inches
above the tack . This cringle allows the installation of a mainsail cunningham if
desired as shown in Figure 10. The cunningham tackle (86A), should be secured
to the upper hole in the aluminum plate (85) protruding from the sail groove at
the base of the mast. The bottom hole should be used for a boom vang if
installed.
The luffs of some No. 1 and No. 2 genoas are also fitted with a cringle and line to
permit the fitting of a simple cunningham as shown in Figure 11. A more
sophisticated arrangement involving a purchase tackle and control line to the
cockpit may be installed if preferred .
