9. Recover trailer, proceed to dock and rig mast.
RIGGING KIT
To rig your boat you will require the following tools:
o
A pair of Vise-grips
o
An adjustable wrench
o
A pair of long nose pliers
o
A marlin spike or awl
o
A roll of vinyl adhesive tape (white electrical tape available at
Canadian Tire)
o
A screwdriver
The parenthesized numbers (1) in the text correspond with the numbers shown in
the drawings.
The standard rigging kit for a Tanzer 22 consists of the following items:
Ref. Figure Description
-1 2A Forestay (5/32 1 x 19) fitted with a swaged eye at each end.
-2 2A Backstay (5/32 1 x 19) fitted with a swayed eye at each end.
-3 2A Two upper shrouds (5/32 1 x 19) Each shroud is fitted with a
swaged eye at one end and a swayed fork at the other.
-4 2B Two lower shrouds (5/32 1 x 19) Each shroud is fitted with a
swaged eye at one end and a swaged fork at the other.
-5 2A
Topping lift (3/32 1 x 19).This is fitted with a thimble at both ends.
Also includes a short length of dacron line.
(6) & (6A)
3E Six turnbuckles each fitted with a toggle
-7 5 Main sheet: (3/8 dia. braided dacron line).
-8 8 Jib sheet: (3/8 dia. braided dacron line).
(9A) 2C Main halyard rope tail: (5/16" dia. twisted dacron line). The wire
portion of the main halyard (3/32" 7 x 7) should already be on
the mast.
(10A) 2C Jib halyard rope tail: 5/16" dia. twisted dacron line). The wire,
portion of this halyard (1/8" 7 x 19) (%) should already be on the
mast.
(11) &
(12)
5 Main sheet blocks. There are two; one is a fiddle block fitted
with a beaked swivel and a cam action jamb cleat (11) and
the other is a fiddle block (12) with a shackle. If your Tanzer 22 is
