Ref. Figure Description
fitted with a traveller, different blocks are supplied, and these
are described in the section dealing with the mainsheet
traveller.
-13 2B Two aluminum spreaders.
-14 7 Jib tack shackle.
Jib Halyard winch handle.
Roller-Reefing handle.
(22A) 2C
Low profile ventilator insert.
RIGGING AND STEPPING THE MAST
1. Support the mast (17) at either end between two blocks or other suitable
supports. There should be two wires already rove through the mast head
fitting; the thinner one is the main halyard (9) and the thicker wire the jib
halyard (10). Both have quick release halyard shackles (18) and (18A) at
one end and a thimble (19) at the other. (see Figure 2a)
