TASKalfa 306ci - Part Names (with Optional Equipments Attached)

To Next Page

To Previous Page

2-5

Installing and Setting up the Machine > Part Names (With Optional Equipments Attached)

Part Names (With Optional Equipments

Attached)

1 Tray 1 to 5 (tray 1 is the top tray)

2 Tray A

3 Finisher Tray

4 Job Separator Tray

5 Cassette 3

6 Cassette 4

7 Cassette 2

Optional Equipment (page 11-2)
