16
D747M
CONTROL PANEL FOR ONE-TWO 12V MOTORS WITH ENCODER
• LOGICS WITH MICROPROCESSOR
• STATUS OF INPUTS SIGNALLED BY LEDs
• “PEDESTRIAN GATE” FUNCTION
• INCORPORATED FLASHING CIRCUIT
• ENCODER SENSOR FOR OBSTACLE DETECTION AND SELF-LEARNING OF TRAVEL
• RECEIVER CONNECTOR
• BATTERY AND BATTERY CHARGER CONNECTOR (OPTIONAL)
• DIAGNOSTICS OF MALFUNCTIONS SIGNALLED BY LED
ATTENTION:
- do not use single cables (with one single wire), ex. telephone cables, in order to avoid
breakdowns of the line and false contacts.
- do not re-use old pre-existing cables.
- we recommend to use the TAU cable code M-03000010C0 to connect the motors to the
control board.
TESTING
When you have completed the connection:
• All the green LS LEDs must be on (each of them corresponds to a Normally Closed input).
The go off only when the controls to which they are associated are operated.
• All the red LS LEDs must be off (each of them corresponds to a Normally Open input). The
light up only when the controls to which they are associated are operated.
TECHNICAL FEATURES
Board power supply 13,5V AC - 50 Hz
Max motor 1 power DC 50 W - 18V DC
Max motor 2 power DC 50 W - 18V DC
Fast acting fuse for protection of input power supply 13,5V AC (F1 - 5x20) F 16 A
Fast acting fuse for motor 1 protection (F2 - 5x20) F 10 A
Fast acting fuse for motor 2 protection (F3 - 5x20) F 10 A
Fast acting fuse for protection of auxiliary circuits 18V DC (F4 - 5x20) F 5 A
Motor power supply circuits voltage 18V DC
Auxiliary device circuits supply voltage 18V DC
Logic circuits supply voltages 5V DC
Operating temperature -20 °C ÷ +55 °C
DIAGNOSTICS LED
DL1 PEDESTRIAN button red LED signal
DL2 OPEN/CLOSE button red LED signal
DL3 ERRORS red LED signal
DL4 STOP button green LED signal
DL5 INTERNAL PHOTOCELL green LED signal
DL6 EXTERNAL PHOTOCELL green LED signal
ENGLISH
