CONTROL PANEL FOR AUTOMATIC BARS
• LOGICS WITH MICROPROCESSOR
• STATUS OF INPUTS SIGNALLED BY LEDs
• “PEDESTRIAN GATE” FUNCTION
• INCORPORATED FLASHING CIRCUIT
• ENCODER SENSOR FOR OBSTACLE DETECTION AND SELF-LEARNING OF TRAVEL
• RECEIVER CONNECTOR
• BATTERY AND BATTERY CHARGER CONNECTOR (OPTIONAL)
• DIAGNOSTICS OF MALFUNCTIONS SIGNALLED BY LED
ATTENTION:
- do not use single cables (with one single wire), ex. telephone cables, in order to avoid
breakdowns of the line and false contacts;
- do not re-use old pre-existing cables;
- we recommend to use the TAU cable code M-03000010C0 to connect the motors to the
control board.
TESTING
When you have completed the connection:
• All the green LS LEDs must be on (each of them corresponds to a Normally Closed input).
The go off only when the controls to which they are associated are operated.
• All the red LS LEDs must be off (each of them corresponds to a Normally Open input). The
light up only when the controls to which they are associated are operated.
TECHNICAL CHARACTERISTICS
Board power supply 13,5 V AC - 50 Hz
Max motor power DC 50 W - 18 V DC
Fast acting fuse for protection of input power supply 13,5 V AC (F1 - 5x20) F 16A
Fast acting fuse for motor protection (F2 - 5x20) F 10A
Fast acting fuse for protection of auxiliary circuits 18 V DC (F3 - 5x20) F 1,6A
Motor power supply circuits voltage 18 V DC
Auxiliary device circuits supply voltage 18 V DC
Logic circuits supply voltages 5 V DC
Operating temperature -20 °C ÷ +55 °C
CONNECTIONS TO TERMINAL BOARD
Terminals Function Description
1 - 2 AUX
auxiliary circuits output 18 V DC max. 15 W for photocells,
relays, receivers, etc... (1 = NEGATIVE - 2 = POSITIVE)
3 - 4 TX PHOTOCELLS
18 V DC output for transmitter photocell – phototest - max.
no. 2 photocell transmitters. (3 = NEGATIVE - 4 = POSITIVE)
5 - 6 FLASHING LIGHT
18 V DC max. 20W output for ashing light supply, ashing
signal supplied by the control unit, rapid for closing, slow for
opening. (5 = NEGATIVE - 6 = POSITIVE)
7 - 8 BAR LED
max. 18 V DC bar LED power output.
(7 = NEGATIVE - 8 = POSITIVE);
