GB
12 V SUPPLY VOLTAGE
BUILT-IN RECEIVER
MICROPROCESSOR LOGIC
ELECTRONIC CONTROL OF MOTOR TORQUE
MOTOR DECELERATION AT THE END OF THE MANOEUVRE
DOOR OPENING-CLOSING DELAY
SELF-LEARNING OF WORK AND PAUSE TIME
CONTROL OF INPUT STATE WITH LEDS
12 V INPUT PROTECTION WITH FUSE
12 V OUTPUT PROTECTION WITH FUSE
BUILT-IN BATTERY CHARGER
CONNECTIONS TO TERMINAL BOARD
12 V dc supply voltage INPUT.
+ Terminal 1, - Terminal 2. Contacts to use only with rectifier card.
12 V dc DRY BATTERY INPUT, 6Ah.
This battery guarantees power to the panel for 24 hours with the panel in waiting state, 20 minutes if the
motor is running (approx. 30 manoeuvres).
+ Terminal 3, - Terminal 4.
12 V dc OUTPUT, max. 80 W.
To power OUTDOOR RECEIVERS, PHOTOELECTRIC CELLS etc.
Protected with an 2A fuse (5x20).
+ Terminal 5, - Terminal 6.
12 V dc M1 motor OUTPUT, max 50 W. Connect motor of door with the electric lock, delayed in CLOSING
(time adjustable with dip switches 7A a 8A).
12 V dc M2 motor OUTPUT, max 50 W (only for MEC 2000 vers.)
Connect motor of door delayed in OPENING (time adjustable with dip switches 7A and 8A).
12 V dc OUTPUT for FLASHING LIGHT, max. 20 W.
+ Terminal 11, - terminal 14, (14=Commun).
With Dip 2B in ON position you can select the COURTESY LIGHT function.
12 V dc INDICATOR LIGHT OUTPUT, max. 15 W.
It is on from the beginning of the opening manoeuvre up until the gate is completely closed.
+ Terminal 12, - terminal 14, (14=Commun).
12 V dc ELECTRIC LOCK OUTPUT, max. 15 W.
It is active for 1 second before and 2-6 seconds after the gate starts opening, delayed in closing (M1).
+ Terminal 13, - terminal 14, (14=Commun).
PEDESTRIAN push button input (Normally Open contact); its function is identical to that of the
OPEN/CLOSE, It depends on DIP-1.
Terminal 15, 17=Common.
OPEN/CLOSE PUSH BUTTON (or STEP-BY-STEP). The function of this input depends on dip
switches 3A and 4A (COMMAND CARD). It is possible, via DS3A, to exclude reversal of direction
during opening, or the OPEN/STOP/ CLOSE/STOP function with DS4A, it depends on DIP-1.
Normally open contact.
Terminal 16, 17=Common.
With DIP-1 in the ON position and 2 motors, both open-close and pedestrian functions are operative
In the OFF position we have the following:
with DIP-8 OFF, open-close and normal pedestrian functions;
with DIP-8 ON, the open-close function becomes open switch only;
with DIP-8 ON, the pedestrian function becomes close switch.
1-2
3-4
5-6
7-8
9-10
11-14
12-14
13-14
15-17
16-17
pag.16
