Taylor 340 Service Instructions

25
Models 340/341/342
Parts
Model 340 Parts Identification
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X39936SSP1
1a BEARING-REAR SHELL 032511
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 GEAR A.*REDUCER 4.92:1 015985-SER
2a COUPLING-DRIVE 018962
3 SCREW-5/16-18X7/8 SERR. 017973
4 PULLEY-AK69 X 5/8 051012
5 BELT-V-4L460 013859
6 PULLEY-AK23-1/2 013997
7 MOTOR-1/4 HP 014477-12
8 SCREW-5/16-18X5/8 SERR. 017326
9 GUIDE A.-DRIP PAN X47190
10 SCREW-10X3/8 SLOTTED HEX 015582
11 CONDENSER-AC-15LX14H 046558
12 SCREW-1/4-20X5/8 SERR. 017522
13 NUT-1/4-20 WHIZ FLANGE LK 017523
14 SHROUD-FAN 052472
15 FAN-5 BLADE 12"PUSH 047279
16
MOTOR-FAN 120 W 115V
60HZ (150V 60HZ 1PH)
041401-12
MOTOR-FAN 80 WATT 1550
RPM (208V 60HZ 1PH)
051744-27
17 BRACKET-FAN 038641
18 SCREW-10-32X3/8 SLTD RND 002742
19 LEG-4"·SS-W/ORING 013458
20 SCREW-10-32X3/8 UNSL HWH 039381
21
BOX A.-CAP&RELAY
(150V 60HZ 1PH)
X50292-12
BOX A.-CAP&RELAY
(208V 60HZ 1PH)
X48892-27E
22 NUT-5/16-18 WHIZ FLANGE 017327
23 SLEEVE-MOUNTING-COMP 039920
24 GROMMET-COMPRESSOR MT 039919
25 WASHER-5/16 USS FLAT CR3 000651
26 SCREW-5/16-18X1-1/2 HEX 001894
ITEM DESCRIPTION PART NO.
27 COMPRESSOR AJA7455ZXA 050301-12
28 SWITCH-PRESSURE 440 PSI 048230
29 VALVE-ACCESS 1/4FL X 3/8S 044455
30 DRYER-FILTER-HP62-3/8 X 1/4 048901
31 VALVE-EXP-AUTO-1/4S X1/4 046365
32 BOLT-CARRIAGE 1/4-20 X 3/4 012347
33 PANEL A.-FRONT X46881
34 SCREW-6-32X3/8 SLTD 002201
35 PLATE-DEC 043456
36 SWITCH A.-TOGGL E X15204
37 SCREW-8X1-1/4 SLTD PAN A 028540
38 WASHER-#10 FLAT 18-8 SS 037841
39
TIMER-DELAY ON MAKE-10
MIN (150V 60HZ 1PH)
029312-12
TIMER-DELAY ON MAKE-10
MIN (208V 60HZ 1 PH)
029312-27
40
LIGHT-AMBER-RECT-120V-1/3
W (150V 60HZ 1PH)
047141-12
LIGHT A.-ADD MIX-AMBER
(208V 60HZ 1PH)
X47218-
41 SWITCH A.-TORQUE X29601-SER
42 ARM A.-ANTICIPATOR X29556-SER
43 SCREW-8X3/8 SAW SLOT PAN 013234
44 BRACKET-SOLENOID 030245
45
SOLENOID-PULL
(150V 60HZ 1PH)
030202-12
SOLENOID-PULL
(208V 60HZ 1PH)
030202-27
46 STUD-NOSE CONE
5/16-18X5/16
013496
47 BRACKET-CONTROL BOX 016197
48 COVER-RELAY BOX 015311
49
CONTROL A. (150V 60HZ 1PH) X52469-12
CONTROL A. (208V 60HZ 1PH) X52469-27
50 PROBEA.-MIX*SQUARE* X30922
51 DISC-PROBE *SQ HOLE* 030965
52 SPACER-PROBE *SQ HOLE* 030966
