Taylor 340 - Control A. X49284 & X49284 SP - Models 341 & 342

40
Parts
Models 340/341/342
Control A. X49284 & X49284SP -- Models 341 & 342
ITEM DESCRIPTION PART NO.
1
RELAY-3 POLE 115V 012725-12
RELAY-3 POLE 208/240 012725-33
2 TERMINAL-RING 023531
3 SCREW-8X1/4 SL HEX HD 009894
4
CONTROL-MIX L EVEL 031799-12
CONTROL-MIX L EVEL 031799-27
5 LUG-GROUNDING 260 020928
ITEM DESCRIPTION PART NO.
6 SCREW-10-32X1/2 MF HEX CAP 020982
7 NUT-10-32 MF LOCK 020983
8 LABEL-GROUNDING SYMBOL 017669
9 SCREW-8 X 1-1/4 RD HD TYP B 039420
10
BLOCK-TERMINAL 2P-L1,N 115V 039421
BLOCK-TERMINL 2P-L1,L2 220V 039422
11 LABEL-COPPER COND ONLY 025948
