31
Models 340/341/342
Parts
120220
Model 341 Operator Parts Identification
Item Description Part No.
1 Cover A.-Hopper X38458
2 Gasket-Hopper Cover 038375
3 Tube-Feed 015176-9
4 Louver-Side--Top 051192
5 Panel-Upper Side (Left/Right) 024576
6 Panel-Rear 013637
7 Panel A.-Lower Side (Left/Right) X24397
8 Trim--Rear Corner 013620
9 Adapter A.-Caster X18915
10 Wheel-Caster 018794
11 Screw--1/4--20 x 3/8 Sltd Rd 011694
12 Angle--Panel--R 013828
Item Description Part No.
13 Caster--4” Swv 5/8 Stem w/Brake 034081
14 Panel-Service 013638-SP1
15 Pan-Drip 035034
16 Tray-Drip 013690
17 Shield-Splash 022763
18 Angle--Panel--L 013829
19 Panel A.-Front X46881
20 Decal --Dec 048359
21 Washer--Plastic Pivot 013808
22 Screw--10--24 x 1/2 Torx Truss 002077
23 Nut--10 --32 Whiz Flange 020983
24 Screw--10--32 x 1/2 Serrated 020982
To Next Page
