38
Parts
Models 340/341/342
120814
Model 342 Beater Door A. -- Self--Closing/Prime Plug Door
ITEM DESCRIPTION PART NO.
1 CAP A. --SPRING--RETAINER X54755
2 SPRING--COMP.970X.082X3.875 030344
3 PLUNGER--CAP DRAW SWITCH 080554
4 PIN--HANDLE--VALVE 064864
5 VALVE--DRAW--SLUSH 080662
6 O--RING -- 1” OD X .139 W 032504
7 DOOR A. --PARTIAL SELF CLOSE X80663
8 O --RING--.563 OD X .070W--#013 043758
9 PLUG --PRIME 050405
10 HANDLE A. DRAW X47384
11 BUSTER--ICE 047735
12 NUT --STUD 029880
ITEM DESCRIPTION PART NO.
13 O--RING -- .291 OD X .080 W 018550
14 ARM -- TORQUE 052450
15 TORQUE A. X14488
16 BEARING -- GUIDE 014496
17 BLADE -- SCRAPER PLASTIC 046237
18 CLIP -- SCRAPER BLADE 046238
19 GASKET -- DOOR 5.177” ID 016672
20 BEARING -- FRONT 013116
21 BEATER A. -- 7 QT. 1 PIN X46233
22 SHAFT -- BEATER 035418
23 SEAL -- DRIVE SHAFT 032560
24 O--RING 7/8 OD X .139 W 025307
