Model 342 Tim Hortons Operator Parts Identification
141212
Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 COVER A.-HOPPER X51152
2 PAN-DRIP 21-1/2" LONG 052827
3 PANEL-SIDE RIGHT 069037-SP
4 BRACKET A.-BUMPER X68881
5 SCREW-1/4-20X3/8 SLTD 011694
6 PANEL-REAR 017563
7
TRIM-REAR CORNER-RIGHT 013663
TRIM-REAR CORNER-LEFT 069040
8 ADAPTOR A.-CASTER X18915
9 CASTER-4" SWV 5/8 STEM 018794
ITEM DESCRIPTION PART NO.
10 SPINNER A.-PANEL MOUNT-R X6836827SP
11 CASTER-4" SWV W/BRAKE 034081
12 PANEL-SERVICE 052091
13 TRAY-DRIP 068714
14 SHIELD-SPLASH 068716
15 PANEL A.-FRONT X52089-SP2
16 SPINNER A.-PANEL MOUNT-L X6836927SP
17 SCREW-10-32X5/8 SLTD 079113
18 PANEL-SIDE LEFT 069036-SP
