Model 342 Tim Hortons Parts Replacement Schedule
Section 9 Parts Replacement Schedule
PART DESCRIPTION EVERY 3 MONTHS EVERY 6 MONTHS ANNUALLY
Drive Shaft Seal X
Drive Shaft O-Ring X
Draw Valve O-Rings X
Prime Plug O-Ring X
Torque Arm O-Ring X
Front Bearing X
Guide Bearing X
Scraper Blades X
Freezer Door Gasket X
Brush-Mix Hopper - 3” x 7” Inspect & Replace
if Necessary
Maximum
Brush-Double-Ended Inspect & Replace
if Necessary
Maximum
Brush-Rear Bearing - 1” x 2” x 14” Inspect & Replace
if Necessary
Maximum
Brush-Draw Valve -1” x 2” x 17” Inspect & Replace
if Necessary
Maximum
Brush-Syrup Port Inspect & Replace
if Necessary
Maximum
