11
Model 342 Tim Hortons Operator Parts Identification
141212
Accessories
Figure 3
ITEM DESCRIPTION PART NO.
1 PAIL-10 QT. 013163
2 BRUSH-MIX PUMP BODY-3 X 7 023316
3 BRUSH-DOUBLE END 013072
4 BRUSH-REAR BRG 1 X 2 X 14 013071
ITEM DESCRIPTION PART NO.
5 BRUSH-DRAW VALVE 1 X 2 X 17 013073
6 BRUSH-SYRUP PORT 045079
* KIT A.-TUNE UP*TORQUE X50413A
* NOT SHOWN
