12
Models 340, 341, 342Operating Procedures
Insert the draw valve into the door, leaving
approximately 1/2” of the valve sticking out the top of
the door.
Figure 9
Rotate the draw valve so the flats on the top of the draw
valve are perpendicular to the door face.
Figure 10
Insert the ice buster through the door spout and into
the slot located just above the lower o-ring.
Figure 11
With the ice buster in place, rotate the draw valve to
allow installation of the draw handle. This will lock the
ice buster in place. Install the draw handle pin, and
close the draw valve by moving the handle to the left.
Figure 12
Place the large rubber gasket into the groove on the
back side of the freezer door.
Figure 13
