Taylor 342 Operating Instructions

31
+ Available Separately
Models 340, 341, 342 Parts List
040823
DESCRIPTION PART
NUMBER
340
QTY.
341
QTY.
342
QTY.
W ARR.
CLASS
REMARKS PARTS
UPDATE
WATER COOLED ACCUMULATOR--CO PPER 2”DIA 10”LG 047062 1 1 2 103 BLOWER--100 CFM 012796-- 1 1 103 BRACKET--MOUNTING--WATER VALVE 038777 1 1 103 CONDENSER--WC--COAX 048287 1 2 103 CONDENSER--WC --SPIRAL 11 --1/2 OD 049309 1 103 GUARD--BLOWER 022505 2 103 HOSE--RUBBER 1/2 ID X 7/8 OD R50200 4 ft. 4 ft. 8 ft. 000 MOTOR--FAN 9 WATT 1550RPM--CW 012768-- 1 103 + FAN--5 BLADE 7 ” PUSH 30DEG CW 016289 1 103 OUTLET A.--TEE X25900 1 103 PANEL A.-- SIDE LOWER X24397 2 103 SWITCH--PRESSURE 350 PSI--SOLDER 048231 1 1 2 103 TEE--3/8” PIPE WATER VALVE 032953 1 103 VALVE--WATER 3/8 REG/HEAD PRESS 046686 1 1 2 103 50Hz BEL T--V--4L470 007994 1 000 BEL T--V--4L410 007530 1 000 BEL T--V--4L440 009387 2 000 BLOCK--TERMINAL--7 POLE GREEN 024156 1 2 103 COMPRESSOR L61B562BBKB 048727--40 1 1 2 512 208/230-50-1 + CAPACITOR--RUN-- 15UF/370V 027087 1 1 2 103 208/230-50-1 + CAPACITOR--STAR T--161--193UF/250V 031790 1 1 2 103 208/230-50-1 + RELAY--START--COMPRESSOR 048766 1 1 2 103 208/230-50-1 DIAGRAM--WIRING *340--341--342* 049359--40 1 1 2 000 MOTOR--FAN 100W 220--240V 50HZ 047178--34 1 1 103 208/230-50-1 PULLEY--AK27--1/2 016190 1 1 2 103 BEATER MOTOR SOFT SLUSH ARM--TORQUE *340/341/342* 029549 1 1 103 TORQUE A. *342 SOFT SLUSH X27027--1 1 1 103 SPRING--TORQUE*RED* 020232 1 1 103
