Taylor 390 Service Manual

4.8 BEVERAGE EQUIPMENT:
4.8.6.3 Iced Cappuccino Machine 4 Issue Date: February 21, 2008
Taylor 390 Last Modified: October 31, 2008
5. Spinner Indicator Lights
ON
OFF
The spinner indicator lights are
located on the front of the
machine, one above each
spinner assembly. The spinner
indicator lights are activated by
pressing the respective spinner
motor switches. The lights
illuminate for 15 seconds,
indicating the proper blend time.
3. Mix Out and 4. Add Mix Indicator Lights
ON
OFF
The “ADD MIX” indicating light is located on the front
of the machine. The indicator light will flash and an
audible tone will sound when the mix hopper has a low
supply of product. Refill the hopper as soon as
possible.
The “MIX OUT” indicating light is located on the front of
the machine. The indicator light will flash to indicate
that the mix hopper is empty and the mix supply needs
to be replenished. To prevent damage to the unit,
refrigeration discontinues automatically.
2. Reset Button
The reset button is located in the left side panel. The reset
protects the beater motor from an overload condition. If an
overload occurs, the reset mechanism will trip. To properly reset
the freezer, place the power switch in the “OFF” position. Press
the reset button firmly. Place the power switch in the “WASH”
position and observe the freezer's performance. Once satisfied,
place the control switch back in the “AUTO” position.
1. Power Switch
The center position is “OFF”. The
“ON/AUTO” (or FREEZE) position
activates the beater motor and
the refrigeration system. The
“WASH” position activates the
beater motor only.
SPINNER
SPINNER
