Taylor 390 - Parts Tray Layout Guide; Parts Placement for Cleaning

4.8 BEVERAGE EQUIPMENT:
4.8.6.3 Iced Cappuccino Machine 5 Issue Date: February 21, 2008
Taylor 390 Last Modified: October 31, 2008
TAYLOR 390 PARTS TRAY
Place parts in the assigned area when cleaning the machine
Beater Shaft
Torque
Assembly
Beater Shaft
O-Ring
Draw Valve
Draw Valve
O-Rings (2)
Valve
Handle Pin
Draw Valve
Handle
Freezer
Door
Door
Gasket
Scraper
Blades (2)
and Clips
Freezer Door
Nuts (4)
Prime
Plug
Beater
Shaft
Ice
Buster
Torque Arm
