4.8 BEVERAGE EQUIPMENT:
4.8.6.3 Iced Cappuccino Machine 9 Issue Date: February 21, 2008
Taylor 390 Last Modified: October 31, 2008
9. Pull the draw handle out and re-align the draw valve position so that it is
perpendicular to the freezer door (see Diagram A) to unlock the ice buster.
10. Using your index finger, push up on the bottom of the draw valve to remove it
from the freezer door.
11. Using a dry Salmon cloth or paper towel, apply pressure in an upward
direction until the O-Ring pops out of its groove. With the other hand, push
the top of the O-Ring forward and it will roll out of the groove and can be
easily removed. Carefully use your fingers to roll the O-Ring off the end of
the draw valve. Repeat process for the second O-Ring.
NOTE: If preferred, the O-Ring Remover Tool can be used to take off the O-
Rings from both the draw valve and the beater shaft (as shown).
12. Remove the door gasket from the freezer door.
Diagram A
