Taylor C152 Service Manual

INTRODUCTION/SAFETY
1-9
Model C152 & C161
Introduction/Safety
1
is available and worn when required during
installation and service.
• Authorized service personnel must remove all
metal jewelry, rings, and watches before
working on electrical equipment.
WARNING! This machine has many sharp
edges that can cause severe injuries.
Examples:
• Scraper blades
• Condenser fins
• Cup/cone dispenser (if applicable)
Electrical Connections
IMPORTANT! In the United States, this
machine is intended to be installed in accordance with
the National Electrical Code (NEC), ANSI/NFPA 701987.
The purpose of the NEC code is the practical
safeguarding of persons and property from hazards
arising from the use of electricity. This code contains
provisions considered necessary for safety.
In all other areas of the world, the machine should be
installed in accordance with the existing local codes.
Please contact your local authorities if you have any
questions.
Each machine requires one power supply for each data
label on the machine. Check the data label(s) on the
machine for branch circuit overcurrent protection or fuse,
circuit ampacity, and other electrical specifications.
See the wiring diagram provided inside the electrical box
for proper power connections.
WARNING! This machine must be properly
grounded! DO NOT operate this machine unless it is
properly grounded and all service panels and access
doors are restrained with screws. Failure to do so can
result in severe personal injury from electrical shock!
IMPORTANT! This machine is provided with
an equipotential grounding lug that is to be properly
attached to either the rear of the frame or the underside
of the base pan near the entry hole for incoming power,
by the authorized installer. The installation location is
marked by the equipotential bonding symbol (5021 of
IEC 604171) on both the removable panel and the
machine’s frame, as well as on the diagram.
IMPORTANT!
• DO NOT operate the machine with larger fuses
than specified on the data label.
• Stationary machines which are not equipped
with a power cord and a plug or another device
to disconnect the machine from the power
source must have an all-pole disconnecting
device with a contact gap of at least 0.125 in.

(3 mm) installed in the external installation.
• Machines that are permanently connected to
fixed wiring and for which leakage currents may
exceed 10 mA, particularly when disconnected,
not used for long periods, or during initial
installation, shall have protective devices to
protect against the leakage of current, such as a
GFI, and be installed by authorized personnel to
the local codes.
• Supply cords used with this machine shall be 
oil-resistant, sheathed, flexible cable, not lighter
than ordinary polychloroprene or other
equivalent synthetic elastomer-sheathed cord
(code designation 60245 IEC 57) installed with
the proper cord anchorage to relieve conductors
from strain, including twisting, at the terminals
and protect the insulation of the conductors
from abrasion.
Failure to follow these instructions may result in
electrocution or damage to the machine.
!
FOLLOW YOUR LOCAL ELECTRICAL CODES.
