Taylor C152 Service Manual

1-2
INTRODUCTION/SAFETY
Model C152 & C161
Introduction/Safety
1
Safety
We at Taylor Company are committed to manufacturing
safe operating and serviceable machines. The many
built-in safety features that are part of all Taylor machines
are aimed at protecting operators and trained service
technicians alike.
NOTICE! This manual is intended exclusively
for Taylor service personnel.
Per IEC 60335-1 and its part 2 standards, this machine is
to be used only by trained personnel. It is not intended for
use by children or people with reduced physical, sensory,
or mental capabilities, or lack of experience and
knowledge, unless given supervision or instruction
concerning the use of the appliance by a person
responsible for their safety.
CAUTION! DO NOT attempt to run the machine
unless you have been properly trained to do so. Failure
to do so can result in personal injury or machine damage.
WARNING! This machine must be properly
grounded! DO NOT operate this machine unless it is
properly grounded and all service panels and access
doors are restrained with screws. Failure to do so can
result in severe personal injury from electrical shock!
WARNING! Avoid injury.
• DO NOT attempt any repairs unless the main
power supply to the machine has been
disconnected.
• DO NOT operate the machine with larger fuses
than specified on the data label.
• Stationary machines which are not equipped
with a power cord and plug or other device to
disconnect the machine from the power source
must have an all-pole disconnecting device with
a contact gap of at least 0.125 in. (3 mm)
installed in the external installation.
• Machines that are permanently connected to
fixed wiring and for which leakage currents may
exceed 10 mA, particularly when disconnected,
not used for long periods, or during initial
installation, shall have protective devices to
protect against the leakage of current, such as a
GFI, and be installed by authorized personnel to
the local codes.
• Supply cords used with this machine shall be
oil-resistant, sheathed flexible cable, not lighter
than ordinary polychloroprene or other
equivalent synthetic elastomer-sheathed cord
(code designation 60245 IEC 57) installed with
the proper cord anchorage to relieve conductors
from strain, including twisting, at the terminals
and protect the insulation of the conductors
from abrasion.
• For Cord-Connected Machines: Only Taylor
service technicians may install a plug on this
machine.
Failure to follow these instructions may result in
electrocution or damage to the machine.
IMPORTANT! This machine is provided with
an equipotential grounding lug that is to be properly
attached to either the rear of the frame or the underside
of the base pan near the entry hole for incoming power,
by the authorized installer. The installation location is
marked by the equipotential bonding symbol (5021 of
IEC 604171) on both the removable panel and the
machine’s frame, as well as on the diagram.
CAUTION! DO NOT remove the machine door
or any internal operating parts (examples: beater, scraper
blades, etc.) unless all control switches are in the OFF
position. Failure to follow these instructions may result in
severe personal injury from hazardous moving parts.
!
