Taylor C152 Service Manual

PARTS
4-7
Model C152 & C161
Parts
4
Model C152 Service Parts
Item Description Part No.
1
Shell A.-Insulated X86356-SER
1a
Bearing-Rear Shell 023648
1b
Tab-Bearing Lock 025027
1c
Nut-Rear Bearing 023647
1d
Collar-Bearing-Rear 025564
2
Gear A.-*Reducer 4 to 1 025770-SER
3
Pulley-10J-4.50PD-5/8B 030455
4
Belt-Poly V-280J10 025776
5
Motor-1/2 HP 059742-12
6
Pulley-10J-1.5 PD-5/8 Bore 025479
7
Hinge A.-Motor X25896
8
Spring-Comp .970 x .115 x 2.00 025707
9
Bushing-Rubber Mount 012258
10
Cap-Rubber Mount 011844
11
Clamp-Mounting 012257
12
Switch A.-Reed Interlock Door X65658-5
13
Motor A.-Condenser Fan (Includes
Items 13A to 13G)
X86552-12
13a
Motor-Fan 062253-12
13b
Shroud-Condenser 051542-SP
13c
Screw-10-32 x 3/8 UNSL HWH 039381
13d
Screw-8 x 1/4 SLTD Hex 009894
13e
Dryer-Cap. Tube .026 ID x 8 048725
13f
Condenser-AC 7 x 6 x 1.25 027155
13g
Harness-Wire Danfoss 086253
14
Mount-Condenser *C152* 086362
15
Screw-10-24X1/2 Torx 002077
16
Screw-10-32X3/8 Serrated 075985
17
Valve-Access-1/4 MFL x 1/4 047016
18
Switch-Pressure 440 psi 048230
19
Valve-Access-1/4 FL x 3/8 044455
20
Compressor 049302-12
21
Sleeve-MT-Comp AE 039920
22
Grommet-Compressor MT 039919
23
Condenser-AC 12L x14H x 1.87T
3RW
046556
24
Screw-10 x 3/8 Slotted Hex 015582
25
Shroud-Fan 086381
26
Fan-4 Blade 11” Push 30 027818
27
Bracket-Fan 025631
28
Motor-Fan 027817-12
29
Guide A.-Drip Pan X86354
30
Fastener-Clip 10-32 U-Type CR3 064719
31
Panel A.-Front 086384
32
Channel A.-Control X86366 See
page 4-17
33
Bolt-Carriage 1/4-20x3/4 012347
34
Switch-Toggle-4PDT 037394
35
Screw-6-36x3/8 SLTD 002201
36
Kit-Mounting-Compress 047704
37
Compressor 047701-12
38
Valve-Access-1/4 FL x 1/4 044404
39
Relay-DPDT 1MA-7A 1/6HP 052111-03
40
Stud-Nose Cone 013496
41
Valve-EXP-Auto-1/4Sx1/4 046365
42
Valve-Solenoid 7/64ORF 043449-12
43
Bracket-Solenoid 086387
44
Dryer-Filter-HP62-3/8 048901
45
Probe A -Mix *Square* X30922
46
Disc-Probe *SQ Hole* 030965
47
Spacer-Probe *SQ Hole* 030966
48
Cover-Control Box 086386
49
Board-Power Gen 2 X69574SER1
50
Control A. 115V 60HZ See page 4-15
Item Description Part No.
