Taylor C152 Service Manual

4-10
PARTS
Model C152 & C161
Parts
4
Model C161 Service Parts
*Not Shown
Item Description Part No.
1 Motor-1/2 HP Remote Cap 055097-27G
2 Nut-5/16-18 Flange Nut 017327
3 Screw-5/16-18x5/8 SERR 017326
4 Pulley-AK20x5/8 041162
5 Valve-Exp-Auto-1/4S x1/4 046365
6 Valve-Solenoid 7/64ORF 043449-27
7 Dryer-Filter 1/4 x 1/4 048878
8 Spacer-Probe *Sq Hole* 030966
9 Disc-Probe *Sq Hole* 030965
10 Probe A.-Mix *Square* X30922
11 Shell A.-Insulated X85022-SER
11a Bearing-Rear Shell 023648
11b Nut-Rear Bearing 023647
12 Gear A.*Reducer 4 to1 025770-SER
13 Washer-5/16 SAE Flat 017660
14 Screw-1/4-20x3 Hex Head 025984
15 Screw-1/4-20x3-1/4 Hex 025985
16 Pulley-5.7” Pitch Dia x 5/8” 041498
17 Belt-AX24 055201
18 Belt-AX45 045311
19 Valve-Sol-1/4 ORFX3/8IN 062019-27
20 Condenser A.-Danfoss X63551-27G
20a Shroud Danfoss 048818
20b Motor-Fan 95.3 CFM 2700 062253-27
20c Screw-10-32x3/8 UNSL HWH 039381
20d Screw-8x1/4 SLTD Hex 009894
20e Condenser-AC 7x6x1.25 027155
20f Dryer-Cap. Tube .021 ID x 9 055522
*20g Harness-Wire-Danfoss 063563
21 Screw-10x3/8 Slotted Hex 015582
22 Cover-Cap.&Relay Box 055136
23 Screw-10-32x1/2 SERR HWH 036054
24 Nut-10-32 Flange Locknut 020983
25 Motor-Fan 50 Watt 029770-27
26 “Fan-3 Blade 12 “” Pull” 063397
27 Shroud-Condenser 064356
28 Condenser-AC 12LX16H 048935
29 Screw-10-32x3/8 UNSL HWH 039381
30 Valve-Access-1/4 MFLX1/4 047016
31 Valve-EPR 1/4s 022665
32 Valve-Access-1/4fl x 1/4 044404
33 Compressor Pl35g 055187-27
34 Kit-MTG-Compressor 047704
35 Control A. *Gen II* See Page 4-16
35a Board-Power-Gen II X69574-SER
36 Cover-Control Box 085260
37 Panel A.-Front X69417
38 Bolt-Carriage 1/4-20x3/4 012347
39 Screw-6-32x3/8 SLTD 002201
40 Plate-Dec *GENII X85289
41 Board-Logic-Gen 2.11 X69571SER3
42 Screw-8x1/4 Sltd Hex 075985
43 Control A.-Channel - 
(See Page 4-18)
X69423
44 Switch-Toggle-4pdt 037394
45 Screw-10-24x1/2 Torx 002077
46 Box A.-Cap&Relay 
(See Page 4-19)
X59557-27G
47 Switch-Pressure 405 psi 052663
48 Compressor L63B562BBCB 048727-27E
49 Screw-5/16-18x1-1/2 Hex 001894
50 Washer-5/16 USS Flat CR3 000651
51 Nut-5/16-18 Flange Nut 017327
52 Screw-1/4-20x1/2 SLT HWH 039381
53 Valve-Access-1/4MFL x 3/8 053565
54 Stud-Nose Cone-5/16-18 013496
*55 Switch A.-Reed Interlock X65658-5
56 Grommet-Comp.-MTG 037428
Item Description Part No.
