PARTS LIST
5-11
Model C152 & C161
Parts List
5
C152 ROHS Compliant
C152 Marine Machine
Model C15240HW00, 220-240V 50 Hz 1PH A/C Tecumseh (R404A). ROHS Compliant
Description Part Number Qty. Warr. Class Comments
Block-Terminal 2P L1, N 039421 1 103
Compressor AKA9462ZXC-AK172JT 049302-40 1 512
+Capacitor Run 15UF/370V 027087 1 103
+Capacitor Start 72-88UF/330V 039567 1 103
+Relay Start Compressor 048150 1 103
Cord-Power-Harmonized 066395-95 1 103
Diagram Wiring *C152* 086047-40 1 000
Harness-Trans Relay A. 086256-40 1 103
Motor 1/2 HP 059742-40 1 103
+Capacitor Run 30 MFD/370V 083338 1 103
+Capacitor Start 130-156UF/33 083339 1 103
Motor-Fan 23.2W 50HZ 027817-34 1 103
+Fan 4 Blade 11 " Pull 30 Deg 027818 1 103
Model C15212HWMU, 115V 60HZ 1PH A/C Tecumseh (R404A) Marine Machine
Description Part Number Qty. Warr. Class Comments
PANEL-REAR *C152* 086376-SPN 1 103
PANEL-RIGHT *C152* 086377-SPN 1 103
PANEL-LEFT *C152* 086378-SPN 1 103
PANEL-LOWER-FRONT *C152* 086380-SPN 1 103
PANEL-FRONT *C152* 086384-SPN 1 103
DIAGRAM-WIRING *C152* 086047-12M 1 000
TRIM-CORNER-REAR *C152* 086375-SPN 2 103
HARNESS-WIRE-CONTROL Box 086257-G 1 103

Taylor C152 Specifications

General

Brand	Taylor
Model	C152
Category	Freezer
Language	English
