5-14
PARTS LIST
Model C152 & C161
Parts List
+ Available Separately
5
Bushing Split 43/64ID x 7/8OD 027691 2 103 Control Box
Bushing Snap 15/16 ID x 1 023396 2 103 Control Channel
Button Reset Red Plastic 055249 2 103
+Eyelet Reset Button 013739 2 103
Cable Ribbon PWR Relay 60 in 032445 2 103
Cap Design 1.010"ID 6 POI 014218 3 000
Compressor L63B562BBCB 048727-27E 1 512 Main
+Capacitor Start 161 193UF/25 031790 1 103
+Capacitor Run 30UF/370V 038487 1 103
+Relay Start Compressor 047067 1 103
+Grommet Compressor Mount 037428 4 000
+Sleeve Mounting Comp. 039924 4 000
+Screw 5/16 18x1 1/2 Hex Head 001894 4 000
Compressor PL35G 055187-27 1 512 Aux May Use X55187SER2 Complete Kit
+Capacitor Start 60UF 220/ 047703 1 000
+Cover Terminal Compressor DN 055357 1 000
+Relay Start Compressor PL 055358 1 000
+Kit Mounting Compressor 047704 1 000
Condenser AC 7X6X1.25 2 Row 027155 1 103 AUX
+Dryer Cap. Tube .021 ID x 9F 055522 1 000 AUX
+Screw 1/4 20x1 Hex Head 017254 4 000
Condenser AC 12LX16HX2.5T 048935 1 103 Main
Contactor 230VAC 1PH 50/60HZ 055248-27 3 103
Cord Power 250V 15A 120"L 068754-27 1 103
Core Schrader Valve Teflon 037047 4 103
C16127F000, 208 230V 60Hz 1PH A/C Bristol (R404A) Standard Machine
Description Part Number Qty. Warr. Class Comments
