5-2
PARTS LIST
Model C152 & C161
Parts List
+ Available Separately
5
C152 Standard Machine
Model C15212H000, 115V 60HZ 1PH A/C Tecumseh (R404A) Standard Machine
Description Part Number Qty. Warr. Class Comments
Actuator-Switch-Plastic 035609 1 103 Draw Switch
Arm A.-Switch X30736 1 103 Draw Switch
Bearing-Front 023262 1 000
Bearing-Guide 014496 1 000
Bearing-Rear Shell *150 52 68* 023648 * 000 See X23648-SER Kit A.-Bearing Rear
Beater A. *150 2 162 168* X24689 1 103
Belt-Poly V 280J10 025776 1 000
Block-Terminal 1P 073423 1 103
Block-Terminal 3 Pole 051331 1 103
Block-Terminal 2P L1,N 039421 1 103
Board-Logic-GEN 2.11 SD/CHM/DF X69571SER3 1 103
+Clamp-Cable-Ribbon 25C Snap 055033 1 000
+Plate-Mounting-Board 085565 1 103
+Screw-6-32X5/8 SLTD Round 019309 4 000
Board-Power GEN 1 & 2 X69574SER1 1 212
+Fuse-.125A-250V-5x20mm-Fast 086029 1 000
Bolt-Carriage-1/4/20x3/4 012347 2 000
Brush-Double Ended-Pump & Feed T 013072 1 000
Brush-Draw Valve 1"ODX2"X17"L 013073 1 000
Brush-Mix Pump Body-3"X7" White 023316 1 000
Brush-Rear BRG 1IN.DX2IN.LGX14 013071 1 000
Bushing-Snap 1 ID x 1-1/4OD 600288 2 103 Control Box and Front Panel
Bushing-Snap 11/16 ID x 7/8 010548 2 103 Control Channel
Bushing-Snap 1-5/16ID x 1-1/ 017008 5 103 Control Box and Front Panel
