5-6
PARTS LIST
Model C152 & C161
Parts List
+ Available Separately
5
Motor-Fan 95.3 CFM 2700 RPM 062253-12 * 103 See - Kit A.-Motor-Fan
Motor-Fan 027817-12 1 103
+Fan 4 Blade 11 " Push 30 Deg CW 027818 1 103
Nut-Stud 034829-SP 2 103
Pail-6 qt. 023348 1 000
Pan-Drip 13-5/16 085295 1 103
Panel-Front 086384 1 103
+Screw-10-24x1/2 Torx Truss 002077 5 000
+Screw-10x3/8 Slotted Hex 015582 5 000
Panel-Lower-Front 086380 1 103
Panel-Rear *C152* 086376 1 103
Panel-Left 086378 1 103
Panel-Right 086377 1 103
Panel-Skirt-Air *C152* 086649 1 103 Only for Machines with legs
Trim-Corner-Rear *C152* 086375 2 103
Plate A.-DEC *C152* X85775 1 103 Complete w/Board
Probe A.-Thermistor-FEM-0.25 X31602-38 * 103 Use X82397-SER Kit A.-Probe-Thermistor
IP68
Probe A.-Mix *Square* X30922 2 103
+Disc-Probe *SQ Hole* 030965 2 103
+Spacer-Probe *SQ Hole* 030966 2 103
Pulley-10J-1.5pd-5/8 Bore 025479 1 103 Beater Motor
Pulley-10J-4.50pd 5/8 Bore 030455 1 103 Gear Reducer
Relay-Start-Compressor 045432-12 1 103 Main
Relay-DPDT 1MA to 7A 1/6HP 052111-03 1 103
Model C15212H000, 115V 60HZ 1PH A/C Tecumseh (R404A) Standard Machine
Description Part Number Qty. Warr. Class Comments
